2PM Connector 5-40A Working Current 500 Mating Cycles Aluminum Alloy

2PM Connector 5-40A Working Current 500 Mating Cycles Aluminum Alloy
2PM Connector 5-40A Working Current 500 Mating Cycles Aluminum Alloy
2PM Connector 5-40A Working Current 500 Mating Cycles Aluminum Alloy 2PM Connector 5-40A Working Current 500 Mating Cycles Aluminum Alloy
Informacion basica
Nombre de la marca: Raymo
Certificación: CE/RoHs/REACH/ISO9001:2015
Número de modelo: 2р 27кн 24г 1в1 в
Minimum Order Quantity: 5
Precio: 1-9.99 USD
Packaging Details: CTN
Delivery Time: 2-3 WEEKS
Condiciones de pago: T/T, D/A, D/P, Western Union, Moneygram
Supply Ability: 5000PCS Per Month
Contactar ahora
Corriente de trabajo: 5-40A Características: Alta durabilidad, fácil de instalar
Ciclos de apareamiento: 500 veces Material: Metal
Contactos: 4/7/8/10/19/20/22/24/32/45/50 Pin Método de conexión: Conexión de hilo
Material de concha: Aleación de aluminio Serie del conector: Conectores 2PM 2PX
Resaltar:

2PM connector 5-40A current

,

aluminum alloy 2PM connector

,

2PM connector 500 mating cycles

2РМТ 27КПН 24Г 1В1 В Working Current 5-40A and Temperature Range -60-200 2PM Connector with Bakelite Insulator
Product Overview
The 2PM Connector is a versatile and reliable electrical component designed for demanding connectivity requirements. With 500 mating cycles, it offers long-lasting performance and exceptional reliability across various applications.
Key Specifications
Working Current 5-40A
Mating Cycles 500 Times
Material Metal
Contacts 4/7/8/10/19/20/22/24/32/45/50 Pin
Connection Method Thread Connection
Shell Material Aluminum Alloy
Temperature Range -60°C to 200°C
Product Features
  • High durability with 500 mating cycles
  • Easy to install with thread connection
  • Multiple contact configurations (4-50 pins)
  • Robust aluminum alloy shell
  • Wide operating temperature range (-60°C to 200°C)
  • Copper contacts with silver/gold plating
  • Bakelite insulator for superior protection
Technical Parameters
Parameter Value
Contact Material Copper With Silver/Gold Plated
Voltage Rating 250V
Termination Style Solder
Mounting Style Through Hole
Shell Size Options 14/18/22/24/27/30/33/36/39/42/45
Applications
The 2PM Connector is ideal for industrial, commercial, and consumer applications requiring reliable electrical connections. Its robust design makes it suitable for harsh environments and applications demanding frequent connections.
Certifications & Compliance
CE, RoHS, REACH, and ISO9001:2015 certified, ensuring quality and environmental compliance.
Support & Services
Comprehensive technical support available for troubleshooting, configuration, and optimal performance of the connector.
